| Fiber Count | Cable OD (mm) | Tensile Resistance (N) Long/Short Term |
Crush Resistance（N/100mm） Long/Short Term |
Bending Radius (mm) Static/Dynamic |
| 2 | 3.0 | 150/300 | 200/1000 | 10D/20D |
| 4 | 5.0 | 150/300 | 200/1000 | 10D/20D |
| 6 | 5.2 | 150/300 | 200/1000 | 10D/20D |
| 8 | 5.5 | 150/300 | 200/1000 | 10D/20D |
| 12 | 6.2 | 300/600 | 200/1000 | 10D/20D |
| 24 | 8.2 | 300/600 | 200/1000 | 10D/20D |
| 36 | 9.5 | 300/600 | 200/1000 | 10D/20D |
| 48 | 10.5 | 300/600 | 200/1000 | 10D/20D |
| Operation Temperature (°C) | -20 ~ +60 |
| Storage Temperature (°C) | -20 ~ +60 |
| Tight Buffer | Blue, orange, green, brown, gray, white, red, black, yellow, purple, pink, aqua Note: ① When the optical fibers in each loose tube is less than 12, they will be colored from the first color (blue) in sequence; ② The fiber color coding can be customized |
| Outer Jacket | Blue, orange, green, brown, gray, white, red, black, yellow, purple, pink, aqua |
| Single Mode Fiber | ||||||
| Unit | G.652D | G657A1 | G657A2 | |||
| Cladding Diameter | μm | 125±1.0 | 125±0.7 | 125±0.7 | ||
| Cladding non-circularity | % | ≤ 1.0 | ≤ 0.7 | ≤ 0.7 | ||
| Core-cladding Concentricity Error | μm | ≤ 0.6 | ≤ 0.5 | ≤ 0.5 | ||
| Coating Diameter | μm | 245±7 | 245±5 | 245±5 | ||
| Coating non-circularity | % | ≤ 6.0 | ≤ 6.0 | ≤ 6.0 | ||
| Cladding-coating concentricity error | μm | ≤ 12.0 | ≤ 12.0 | ≤ 12.0 | ||
| Cable Cutoff Wavelength (λcc) | nm | ≤ 1260 | ≤ 1260 | ≤ 1260 | ||
| Mode Field Diameter | 1310nm | μm | ≤ 0.4 | ≤ 0.4 | ≤ 0.4 | |
| 1550nm | μm | ≤ 0.3 | ≤ 0.3 | ≤ 0.3 | ||
| Multimode Fiber | ||||||
| Unit | 62.5/125 | 50/125 | OM3 | OM4 | ||
| Core Diameter | μm | 62.5±2.5 | 50±2.5 | 50±2.5 | 50±2.5 | |
| Cladding Diameter | μm | 125±1.0 | 125±1.0 | 125±1.0 | 125±1.0 | |
| Core Non-circularity | % | ≤ 5.0 | ≤ 5.0 | ≤ 5.0 | ≤ 5.0 | |
| Cladding Non-circularity | % | ≤ 1.0 | ≤ 1.0 | ≤ 1.0 | ≤ 1.0 | |
| Core-cladding Concentricity Error | μm | ≤ 1.5 | ≤ 1.5 | ≤ 1.0 | ≤ 1.0 | |
| Coating Diameter | μm | 245±7 | 245±7 | 245±7 | 245±7 | |
| Coating Non-circularity | % | ≤ 6.0 | ≤ 6.0 | ≤ 6.0 | ≤ 6.0 | |
| Cladding-coating Concentricity Error | μm | ≤ 12.0 | ≤ 12.0 | ≤ 12.0 | ≤ 12.0 | |
| OFL Bandwidth | 850nm | MHz·km | ≥ 160 | ≥ 500 | ≥ 1500 | ≥ 3500 |
| 1300nm | MHz·km | ≥ 500 | ≥ 500 | ≥ 500 | ≥ 500 | |
